Pepperl+Fuchs
IO-Link
ICE1-8IOL-G60L-V1D
| UL File Number | E223772 |
|---|---|
| MTTF | 574 a |
| LED indication | see manual |
| Rotary switch | Setting the fieldbus protocol |
| Rated Çalışma gerilimi | 18 ... 30 V |
IO-Link master
- Multiprotocol-compatible
- M12 power connector
- Sturdy metallic Gövde
- Web-based configuration
Ethernet IO-Link module with 8 inputs/outputs
ICE1-8IOL-G60L-V1D
| UL File Number | E223772 |
|---|---|
| MTTF | 574 a |
| LED indication | see manual |
| Rotary switch | Setting the fieldbus protocol |
| Rated Çalışma gerilimi | 18 ... 30 V |
| Nominal voltage | 24 V DC |
| Current consumption | typ. 200 m A |
| Current loading capacity | Max. 2 x 16 A per module · (Loop-through current via L-coded power supply) · Total current: max. 9 A per module |
| Galvanic isolation | between US and UL |
| Interface type | Industrial Ethernet |
| Physical | M12, D-coded |
| Protocol | PROFINET IO with media redundancy protocol (MRP) · Ether Net/IP with Device Level Ring (DLR) |
| Transfer rate | 10/100 Mbps |
| Number/Type | 4 x IO-Link Class A (X1 – X4) · 4 x IO-Link Class B (X5 – X8) · Configurable as: · max. 8 IO-Link and 4 digital inputs and outputs · max. 12 digital inputs and 4 digital outputs · max. 12 digital outputs and 4 digital inputs · kısa devre korumalı |
| Sensor supply | max. 500 m A per port (X1 - X8) via L+ (pin 1) |
| Output current | max. 500 m A per port (X1 - X8) Via C/Q (pin 4) · In addition, a maximum of 2 A per port (X5 – X8) Via UAux (pin 2) |
| Directive 2014/30/EU | EN 61000-6-2:2005, EN 61000-6-4:2007+A1:2011 |
| Koruma sınıfı | EN 60529:2000 |
| Fieldbus standard | Type 1 according to IEC 61131-2 |
| Emitted interference | EN 61000-6-4:2007+A1:2011 |
| Noise immunity | EN 61000-6-2:2005 |
| Shock resistance | EN 61131-2:2004 |
| Ortam sıcaklığı | -20 ... 70 °C (-4 ... 158 °F) |
| Storage temperature | -40 ... 70 °C (-40 ... 158 °F) |
| Cold start temperature | -40 °C (-40 °F) |
| Relative humidity | max. 95 % |
| Altitude | 0 ... 2000 m |
| Shock and impact resistance | 50 g, 11 ms, all axes |
| Vibration resistance | 15 g at 5 - 500 Hz |
| Pollution degree | 3 |
| Contact elements | PA |
| Bağlantı | Power Supply M12, L-coded · Fieldbus M12, D-coded · Inputs/Outputs M12, A-coded |
| Contacts | Cu Sn, gold-plated · Cu Ni, gold-plated |
| Gövde | Diecast zinc |
| Seal | FKM |
| Ağırlık | 500 g |
| Sıkma torku, bağlama vidaları | 1 Nm |
| Sıkma torku, Kablo gland | 0.6 Nm |
| Yükseklik | 200 mm |
| Genişlik | 59.6 mm |
| Uzunluk | 21 mm |
| Yapı tipi | Field Gövde |
| Sıkma torku of clamping screws | 0.5 Nm |
