Pepperl+Fuchs
Ultrasonik Sensörler
UC500-30GM-E6R2-V15
| Sensing range | 30 ... 500 mm |
|---|---|
| Adjustment range | 50 ... 500 mm |
| Dead band | 0 ... 30 mm |
| Standard target plate | 100 mm x 100 mm |
| Transducer frequency | yak. 380 k Hz |
Ultrasonik sensör
- Parameterization interface for the application-specific adjustment of the sensor setting via the service program ULTRA 3000
- 2 programmable switch outputs
- Hysteresis mode selectable
- Window mode selectable
- Synchronization options
- ayarlanabilir acoustic power and sensitivity
- Temperature compensation
Single head system, Parameterization interface for the application-specific adjustment of the sensor setting via the service program ULTRA 3000, 2 programmable switch outputs, Hysteresis mode selectable, Seri: UC-30GM, Çalışma gerilimi: 10 … 30 V DC , ripple 10 %SS, Interface type: RS 232, 9600 Bit/s , no parity, 8 data bits, 1 stop bit, Çıkış tipi: 2 switch outputs PNP, NO/NC, programmable, UL onayı: c ULus Listed, General Purpose
UC500-30GM-E6R2-V15
| Sensing range | 30 ... 500 mm |
|---|---|
| Adjustment range | 50 ... 500 mm |
| Dead band | 0 ... 30 mm |
| Standard target plate | 100 mm x 100 mm |
| Transducer frequency | yak. 380 k Hz |
| Response delay | 21 ms minimum · 63 ms factory setting |
| LED yeşil | solid: Power-on · flashing: Standby mode or program function object detected |
| LED sarı 1 | solid: switching state switch output 1 · flashing: program function |
| LED sarı 2 | solid: switching state switch output 2 · flashing: program function |
| LED kırmızı | solid: temperature/program plug not connected · flashing: fault or program function object not detected |
| Temperature/teach-in connector | Temperature compensation , Switch points programming , output function setting |
| Çalışma gerilimi | 10 ... 30 V DC , ripple 10 %SS |
| Boşta besleme akımı | ≤ 50 m A |
| Time delay before availability | ≤ 450 ms |
| Interface type | RS 232, 9600 Bit/s , no parity, 8 data bits, 1 stop bit |
| Synchronization | bi-directional · 0 level -UB...+1 V · 1 level: +4 V...+UB · input impedance: > 12 KOhm · synchronization pulse: ≥ 100 µs, synchronization interpulse period: ≥ 2 ms |
| Common mode operation | max. 95 Hz |
| Multiplex operation | ≤ 95 Hz / n , n = number of sensors , n ≤ 5 |
| Çıkış tipi | 2 switch outputs PNP, NO/NC, programmable |
| Rated Çalışma akımı | 200 m A , short-circuit/overload protected |
| Gerilim düşümü | ≤ 2.5 V |
| Repeat accuracy | ≤ 0.1 % of full-scale value |
| Anahtarlama frekansı | ≤ 7 Hz |
| Range hysteresis | 1 % of the adjusted operating range (default settings), programmable |
| Temperature influence | ≤ 2 % from full-scale value (with temperature compensation) · ≤ 0.2 %/K (without temperature compensation) |
| Standartlar | EN IEC 60947-5-2:2020 · IEC 60947-5-2:2019 |
| UL onayı | c ULus Listed, General Purpose |
| CCC onayı | CCC onayı / marking not required for products rated ≤36 V |
| Ortam sıcaklığı | -25 ... 70 °C (-13 ... 158 °F) |
| Storage temperature | -40 ... 85 °C (-40 ... 185 °F) |
| Bağlantı tipi | Connector plug M12 x 1 , 5-pin |
| Koruma sınıfı | IP65 |
| Gövde | stainless steel (1.4305 / AISI 303) · PBT plastic parts |
| Transducer | epoxy resin/hollow glass sphere mixture; polyurethane foam |
| Ağırlık | 140 g |
| Uzunluk | 94 mm |
| çap | 30 mm |
| Output 1 | Switching point: 60 mm · output function: Switch point operation mode · output behavior: NO contact |
| Output 2 | Switching point: 500 mm · output function: Switch point operation mode · output behavior: NO contact |
